System
Main Processor Quad-core embedded processor
Operating System Embedded LINUX
Display
Interface 1 HDMI (1 HDMI up to 3840 x 2160), 1 VGA
Resolution 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Multi-screen display 1/4/8/9/16
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video Detection and Alarm
Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video Detection Motion Detection, MD Zones: 396 (22 x 18), Video Loss and Tampering
Alarm input 4 channel, Low Level Effective, Green Terminal Interface
Relay Output 2 channel, NO/NC Programmable, Green Terminal Interface
Playback and Backup
Sync Playback 1/4/9/16/25/36
Search Mode Time/ Date, Alarm, MD and Exact Search (accurate to second)
Playback Function Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup Mode USB Device/ Network/ Internal SATA burner
Storage
Internal HDD 2 SATA Ports, up to 6TB capacity for each HDD
HDD Mode Single
Auxiliary Interface
USB 2 ports (1 Rear USB3.0,1 Front USB 2.0)
RS232 1 Port, for PC Communication and Keyboard
RS485 1 Port, for PTZ Control
Audio and Video
IP Camera Input 32 channel
Two-way Talk 1 channel Input, 1 channel Output, RCA
Recording
Compression H.265/ H.264/ MJPEG/ MPEG4
Resolution 12MP/ 8MP/ 6MP/ 5MP/ 4MP/ 3MP/ 1080P/ 720P/ D1 & etc.
Record Rate 320Mbps
Bit Rate 16kbps~20Mbps for per channe
Record Mode Manual, Schedule (Regular (Continuous), MD, Alarm), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Network
Interface 1 RJ-45 port (10/100/1000Mbps)
Ethernet Port 1 Independent 1000Mbps Ethernet Port
Network Function HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search (Support Dahua IP camera, DVR, NVS and etc.), P2P
Max. User Access 128 users
Smart Phone iPhone, iPad, Android
Interoperability ONVIF 2.4, CGI Conformant
Electrical
Power Supply Single, 12VDC/4A
Power Consumption
Dimensions 1U, 375 x 281.5 x 56mm
Weight 1.6kg
